Lithium Batteries
Lithium batteries
Deep cycle and Standdby Applications
Good charge retention
Industrial and solar off grid applications
Perfect Battery for bespoke Projects and Integrated
Systems
Scalable from 5 kWh to 320 kWh
Maximum Flexibility for any Application with up to 64
Modules
Connected in Parallel
Compatible with Market Leading 1 and 3 Phase
Inverters
Cobalt Free Lithium Iron Phosphate (LFP) Battery: Maximum
Safety,
Lifespan and Power
Capable of High-Powered Emergency-Backup and Off-Grid
Function
Self-Consumption Optimization for Residential and
Commercial Applications
Pylontech RT12100 12.8V 100Ah 1280Wh Lithium Iron
Phosphate (LiFePO4)
IP67 Battery with RS485 / CAN / Bluetooth and Dry
Contact Communications.
Connect up to 4 in series and 4 in parallel for 48V
400Ah.
Cycle life: >2000 cycles (100% DoD to 80% of original
capacity) @ 25°C
Max. continuous discharge current: 100A
Standard charge current: 8.4A
Max. cont. charge current: 42A
Charge voltage: 14.2V - 14.6V (14.2V recommended)
Operating Discharge temperature: -20°C to
+60°C
Operating Charge temperature: +0°C to +45°C
Storage temperature: -20°C to +45°C
Series Connection: Up to 4S
Parallel Connection: Nil
Cycle life: >2000 cycles (100% DoD to 80% of original
capacity) @ 25°C
Max. continuous discharge current: 100A
Standard charge current: 8.4A
Max. cont. charge current: 42A
Charge voltage: 14.2V - 14.6V (14.2V recommended)
Operating Discharge temperature: -20°C to
+60°C
Operating Charge temperature: +0°C to +45°C
Storage temperature: -20°C to +45°C
Series Connection: Up to 4S
Parallel Connection: Nil
